Project Case Study: High-Tonnage Industrial Crushing Systems using Hydraulic Double Roller Technologies

Maximizing mineral liberation and high-grade construction aggregate yield via advanced electromechanical-hydraulic integration loops.

1. Project Profile & Objectives

This industrial case study details the deployment of our Large-Scale Hydraulic Double Roller Crusher within high-capacity mining and quarrying operations. Engineered specifically for demanding material reduction environments, this setup delivers a highly reliable solution for processing hard rocks, metal ores, and dense aggregate materials.

By integrating responsive electromechanical-hydraulic control loops, the operational system utilizes high-pressure static extrusion instead of traditional high-velocity impact forces. This deliberate engineering choice effectively reduces the generation of wasted fines (over-crushing) and guarantees continuous, energy-efficient sizing across mega infrastructure circuits.

Large Double Roller Crusher Operating On-Site

2. Core Performance Benchmarks

• Responsive Hydraulic Tramp Relief SystemThe integrated system instantly retracts the movable roll framework whenever uncrushable foreign hazards (such as steel debris or tramp iron) enter the cavity. This automatic fast-bypass avoids core structural fractures and permits non-stop 24/7 operations.

• High Crushing Efficiency & Energy SavingsBy substituting dynamic impact force with high-pressure static extrusion, our units save 20% to 30% in operational energy consumption while expanding overall output limits by 30% to 40% compared to legacy crushing circuits.

• Premium Wear Components & Extended LifecyclesRoller skins are cast from high-chromium manganese steel alloys, yielding 3-5 times longer service life in harsh abrasive conditions. The smart layout uses modular roller components for swift, uncomplicated replacement.

• Automated Sizing & Premium Cubic GeometryReal-time PLC controls modify the physical roller gap seamlessly, producing premium cubic finished product profiles with minimum elongated needle-flake fractions to meet rigid global gradation standards.

• Environmental Compliance FrameworkEngineered with a fully enclosed structural framework combined with targeted dust collection setups, the crushing plant safely suppresses low-frequency noise and airborne particulates.

3. Operational Mechanics

The system executes efficient, repeatable material sizing based on a calibrated static pressure extrusion principle. This controlled mechanics loop regulates sizing distribution while optimizing energy curves:

1. Uniform Gravity Feeding: Raw bulk materials are directed smoothly from the surge bins into the primary crushing throat positioned directly above the counter-rotating rolls.

2. Dynamic Pinch Engagement: High friction coefficients on the roller surfaces naturally pull the incoming rock masses downward into the tightening reduction zone.

3. Concentrated Static Compression: Heavy-duty hydraulic cylinders apply intense continuous pressure. As this crushing force surpasses the rock’s compressive threshold, internal fractures propagate instantly along material boundaries.

4. Calibrated Gravity Discharge: The fully processed cubic aggregates exit freely through the predefined gap spacing at the base of the machine, maintaining an efficient, non-clogging material flow.

4. Technical Parameters & Specifications

Model	Roll Diam. (mm)	Roll Width (mm)	Max Feed (mm)	Capacity (t/h)	Power (kw)
2PGY750×500	φ750	500	≤40	20 – 30	2×(22-30)
2PGY800×600	φ800	600	≤40	30 – 40	2×(30-37)
2PGY800×800	φ800	800	≤40	40 – 50	2×(37-45)
2PGY1000×800	φ1000	800	≤40	50 – 80	2×(45-55)
2PGY1000×1000	φ1000	1000	≤60	80 – 100	2×(75-90)
2PGY1200×1000	φ1200	1000	≤80	100 – 120	2×(75-132)
2PGY1500×1200	φ1500	1200	≤120	150 – 200	2×(132-160)
2PGY1800×1000	φ1800	1000	≤100	250 – 300	2×(250-315)
2PGY2000×1200	φ2000	1200	≤120	300 – 400	2×(315-355)

Large Double Roller Crusher Operating On-Site

5. Cross-Industry Plant Integrations

• Mineral Processing CircuitsHigh-precision reduction of abrasive iron ore, gold matrices, copper runs, and heavy dolomite beds. Operates upstream of raw ball mills to scale up circuit grinding limits.

• Construction Aggregates ProductionSupplies premium manufactured sand (M-Sand) and cubical micro-gravel for structural concrete batching operations requiring strict geometric compliance.

• Cement Manufacturing LinesManages raw mill crushing feedstocks, clinker reduction, coal gangue preparation, and modular gypsum board sizing loops.

• Metallurgy & Solid Slag RecoveryHandles pre-treatment of power plant coking coal while reducing high-hardness steel slag, furnace sinter runs, and quicklime components.

• Resource Regeneration & Solid WasteCrushes old building frameworks, concrete debris blocks, brick fragments, and processing tailings to accelerate regional eco-safe resource circulation.

• Chemical Raw MaterialsDelivers tightly distributed gradations for highly sensitive quartz runs, abrasive feldspar stones, phosphate rocks, and refractory brick composites.

Request a Specialized Project Case Analysis

Our heavy equipment engineering division can model roller shell wear profiles and simulate throughput capacities matching your precise site rock parameters.
